Product Details:
|
| Power: | 220V/50HZ | Color: | Blue-White |
|---|---|---|---|
| Condition: | New | Sorting Accuracy(%): | ≥99.99 |
| Function: | Color Sorter,sorting Different Color Materials | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Field Maintenance And Repair Service,Online Support,Field Installation,commissioning And Training |
| High Light: | Optical Plastic Color Sorter Machine,Flake Plastic Color Sorter Machine,8 Chutes flake sorter |
||
How The Color Sorter Works
The selected material enters the machine from the hopper at the top. Through the vibration of the vibrator device, the selected material slides down the channel, accelerates its falling into the observation area in the separation room, and passes through the sensor and the background plate. Under the action of the light source, according to the light intensity and color change, the system generates an output signal to drive the solenoid valve to blow out the heterogeneous particles to the waste chamber of the receiving hopper, and the good selected material continues to fall into the finished product chamber of the receiving hopper, so as to achieve the purpose of separation.
Technical Parameters
|
Model |
6SXZ-512A |
|
Accuracy |
99.99 |
|
Optical Carryover |
30:1 |
|
Capacity |
6.0-12.0 |
|
Power |
5.0 |
|
Air Pressure |
0.6-0.8 |
|
Air Consumption |
≤3.6 |
|
Dimension(mm) |
3486*1560*1800 |
|
Weight |
1750 |
Plastic Processing
Advantage of Jietai Color Sorter
1.No need to debug, you can use after power-on, without any special experience.
2.Easy to operate,one-click to choose the sorting modes, such as normal rice, japonica rice, glutinous rice, black rice and red rice.
3.The quality is controllable, you can adjust the sorting accuracy freely to meet the needs of differentiated processing and the sorting performance is up to 99.99%.
4.It can do second sorting,low consumption and carryover ratio is more than 30:1,the income is guaranteed.
5.The output is flexible, and it can process 3.0-6.0 tons per hour, which can meet the needs of various processing easily.
6.Intelligent ejectors and ultra-low air consumption to achieve low carryover ratio.
7.Intelligent self-inspection, dust removal and anti-breakage, automatic dust cleaning and automatic adjustment of signals and lights to maintain the best color sorting state.
8.Worry-free after-sale service, free regular inspection and quality guaranteed.
Sorting Application
In the recycling industry,the color sorter can distinguish between colored and colorless PET and colored and colorless HDPE flakes,and can separate flakes by color before repelling.Plastic color sorter are used to separate mixed color plastic flakes or particles.Plastic type color sorter (sensor-based sorting technology) are used to separate plastics of the same color but different materials.The industry-recognized technology is to use a chute color sorter to classify plastic particles.
JIETAI Color Sorter Core Parts
Cooperation Case
Our machine can be found everywhere in Thailand,China,India,Algeria,Bangladesh,Myanmar
and others more countries.
Packaging&Shipping
Our products use professional wooden cases with PE plastic bag..Package size will depend on each model size.
Our Service
Before sales services
We will help you know about our color sorter,meets your special requirement according to actual condition.If you want to have your own logo printed on the macine or want to customize your own color for the machine, tell us,we can help you.
After sales services
1. Provide free training,consulting and technical support for users;
2. Provide personalized programs to the demands of customers;
3. Upgrade software for free for a life time;
4. Provide free warranty service for one year(except the wearing spare parts);
5. Provide 7*24 hours consultation and urgent servicce for users.
Contact Us
FAQ
1.Q:How about the guarantee period?
A:The color sorter(excluding the wearing parts) is warranted for one year for free from date of purchase.we provide a lifetime maintenance service.
2.Q:Will you accept L/C as payment?
A:L/C ,T/T is OK.
3.Q:How about engineers service oversea?
A:Engineers available to service machinery overseas.
4.Q:How to use the machine?
A:We will supply customer the installation catalog or video online.We will ask our engineer to teach you and Our engineers will also train your person when they go to your place for debugging.
5.Q:How about the sample machines for testing?
A:Sample sending for testing is welcomed.Or you send these three photos,the raw material,good material (which is you want) ,bad material (which is you want to discard).We send our sorting video to you.
6.Can you supply the accessories parts of color sorter?
A:Yes,we can supply some spare parts when you need.
