Product Details:
|
| Application: | Grain Sorting | Capacity(T/H): | 0.8-1.6 |
|---|---|---|---|
| Power: | 220V/50HZ | Color: | Blue-White |
| Condition: | New | Sorting Accuracy(%): | ≥99.99 |
| Dimension(l*w*h): | 785*1397*1497mm | Function: | Color Sorter,sorting Different Color Materials |
| High Light: | Custom Spices Color Sorter,CCD Spices Color Sorter,Mini rice color sorting machine |
||
Raw materials are put into the machine from its material hopper on the top, vibrated by vibratory feeder and sliding along material chute into the zone of observation in sorting chamber through sensors and background plate. Under the effect of lamps source, CCD sensor receives compound light from materials being sorted.According to the light intensity and color changes, make the system produce output signal and drive solenoid valve(ejector) to work,ejecting the discolor grain to reject chamber and good materials continue to fall into the finished accept chamber.
Technical Parameters
|
Model NO. |
6SXM-80A |
|
Accuracy (Percent) |
99.99 |
|
Optical Carryover (Bad:Good) |
30:1 |
|
Capacity (T/H) |
0.8-1.6 |
|
Power (kwh) |
1.5 |
|
Air Pressure (Mpa) |
0.6-0.8 |
|
Air Consumption (L/M) |
≤0.6 |
|
Dimension(mm) (L*W*H) |
758*1397*1497 |
|
Weight (kg) |
260 |
Pepper Processing
Sorting Performance
Our Small Type Color Features
1. economical and practical;stable performance;small footprint.
2. the combination of shape selection and color selection;good sorting effect.
3. intelligent and multi-function;effectively remove all kinds of material impurities.
4. Suitable for household self-use and small processing plant.
Cooperation Case
Our machine can be found everywhere in China,Thailand,India,Bangladesh,Philippines and others more countries.
Packaging&Shipping
Our products use professionalwooden cases with PE plastic bag..Package size will depend on each model size.
Our Service
Before sales services
We will help you know about our color sorter,meets your special requirement according to actual condition.If you want to have your own logo printed on the macine or want to customize your own color for the machine, tell us,we can help you.
After sales services
1. Provide free training,consulting and technical support for users;
2. Provide personalized programs to the demands of customers;
3. Upgrade software for free for a life time;
4. Provide free warranty service for one year(except the wearing spare parts);
5. Provide 7*24 hours consultation and urgent servicce for users.
