Product Details:
|
| Application: | Grain Sorting | Capacity(T/H): | 0.8-1.6 |
|---|---|---|---|
| Power: | 220V/50HZ | Color: | Blue-White |
| Condition: | New | Sorting Accuracy(%): | ≥99.99 |
| Dimension(l*w*h): | 785*1397*1497mm | Function: | Color Sorter,sorting Different Color Materials |
| High Light: | CCD tea colour sorter machine,RGB tea colour sorter machine,CCD sesame color sorter |
||
Color Sorter Working Principle
Color Sorter working principle is to use the photoelectric detection technology and image acquisition system to obtain the (RGB) red, green and blue optical information of the material, convert the optical characteristics of the material into a photoelectric signal, and then send the signal to the control system to drive the ejector uses compressed air to blow out foreign particles in the material.
Technical Parameters
|
Model NO. |
6SXM-80A |
|
Accuracy (Percent) |
99.99 |
|
Optical Carryover (Bad:Good) |
30:1 |
|
Capacity (T/H) |
0.8-1.6 |
|
Power (kwh) |
1.5 |
|
Air Pressure (Mpa) |
0.6-0.8 |
|
Air Consumption (L/M) |
≤0.6 |
|
Dimension(mm) (L*W*H) |
758*1397*1497 |
|
Weight (kg) |
260 |
Are you Satisfied with the Current Grain Processing Results ?
Unsatisfied with price?
Unhappy with clean accuracy?
Upset with daily productivity?
Annoyed with too much waste?
JIETAI Color Sorter Can Sloves All Your Headache Problems!
Application Fields
It can sort kinds of grains,like corn,wheat,buckwheat,oat,sesame,barley.It can also works for cereals,beans,and so on.
Cooperation Case
Packaging&Shipping
Our products use professionalwooden cases with PE plastic bag..Package size will depend on each model size.
Our Service
Our Service Team
Before sales services
We will help you know ahout our color sorter,meets your special requirementaccording to actual condition.
After sales services
1. Provide free training,consulting and technical support for users;
2. Provide personalized programs to the demands of customers;
3. Upgrade software for free for a life time;
4. Provide free warranty service for one year(except the wearing spare parts);
5. Provide 7*24 hours consultation and urgent servicce for users.
