Product Details:
|
| Power: | 220V/50HZ | Type: | Rice Sorting Machine |
|---|---|---|---|
| Condition: | New | Production Capacity: | 4-6T/H |
| Color: | Blue | Sorting Accuracy(%): | ≥99.99 |
| Power(w): | 3.5KW | ||
| High Light: | ODM Beans Color Sorter,CCD Beans Color Sorter,CCD coffee bean sorting machine |
||
Working Principle of Color Sorters
Raw Materialare put into the machine from its feeding hopper on the top,vibrated by vibration device and sliding along material chute into the zone of observationin sorting chamberthrough sensor andbackground plate.Under the effect of light source,CCD sensor receives compound light from materials being sorted.According to the light intensity and color changes,make the system produce output signal and drive solenoid valve to work ,ejecting the discolor grain to defect chamber and good materials continue to fall into the finished goods chamber.
Technical Parameters
| MODEL | 6SXZ-448A |
| Chutes/Channels | 6/384 |
| Throughput(T/H) | 4-8 |
| Accuracy(Percent) | ≥99.99% |
| Power(Kwh) | 3.5 |
| Power Voltage | 220V/50Hz |
| Air compressure(Mpa) | <2.2 |
| Weight(Kg) | 1350 |
| Dimension(L*W*H) | 2800*1560*1800mm |
Sorting performance
It's mainly use in sorting beans,such as soybeans,Mung,Red Bean and so on.It features high pure rate,low loss and stable performace.
Packaging Details and Shipping
Our products use professionalwooden cases with PE plastic bag.Package size will depend on each model size.
Our Service
Our Service Team
Before sales services
We will help you know ahout our color sorter,meets your special requirementaccording to actual condition.
After sales services
① Provide free training,consulting and technical support for users;
② Provide personalized programs to the demands of customers;
③ Upgrade software for free for a life time;
④ Provide free warranty service for one year(except the wearing spare parts);
⑤ Provide 7*24 hours consultation and urgent servicce for users.
