Product Details:
|
| Application: | Plastics Sorting | Capacity(T/H): | 5-8 |
|---|---|---|---|
| Color: | Blue-White | Condition: | New |
| Sorting Accuracy(%): | ≥99.99 | Dimension(l*w*h): | 2455*1524*1790mm |
| Function: | Color Sorter,sorting Different Color Materials | Voltage: | 220V/50HZ |
| Power(kw): | 3.0 | Type: | Grain Processing Equipment,Automatic,color Sorter Machine,Rice Mill Production Line,Rice Prossessing Equipment |
| High Light: | 5 Chutes Spices Color Sorter,vibrated Spices Color Sorter,Vibrated rice colour sorter machine |
||
Color Sorters are machines used on the production lines in bulk food processing and other industries.They sort materials by their colors or shapes, If it is found that there are unqualified materials or impurities in the materials, the ejector will blow out the rejects in the hopper.
Technical Parameters
| MODEL | 6SXZ-320A |
| Chutes/Channels | 5/ 320 |
| Throughput(T/H) | 5-8 |
| Accuracy(Percent) | ≥99.99% |
| Power(Kwh) | 3.0 |
| Power Voltage | 220V/50Hz |
| Air compressure(Mpa) | 0.6-0.8 |
| Air Consumption(L/M) | <3.0 |
| Weight(Kg) | 1400 |
| Dimension(L*W*H) | 2455*1524*1790mm |
Working Principle of Color Sorters
Raw Material are put into the machine from its feeding hopper on the top,vibrated by vibration device and sliding along material chute into the zone of observationin sorting chamberthrough sensor andbackground plate.Under the effect of light source,CCD sensor receives compound light from materials being sorted.According to the light intensity and color changes,make the system produce output signal and drive solenoid valve to work ,ejecting the discolor grain to defect chamber and good materials continue to fall into the finished goods chamber.
Product Features
►IOT color sorter system
Highly humanized interface of human-machine interaction, Smart cloud interconnect , Remote control, accurate big data statistics and analysis.Call the multiple preset color selection modes at any time.
►HD image capture system
Full-color high-speed CCD sensor recognizes 0.04mm²area,Nikon camera,super high resolution,ultra-sensitive ,wide vision, low distortion.
►Multi-core parallel image processing system
Multi-core parallel image processing system, flexible matching and synchronous operation of color sorting/shape sorting.
►Intelligent high-frequency solenoid valve
Ultra-low air consumption, ultra-low carryover ratio, intelligent detect the working status of ejectors,avoid the fault and prolong the life of ejectors.
►Shadowless colorful spectrum LED
Taiwan Yiguang,shadow-less LED colorful light source, multi-angle shadow-less light path technology.
►Input and Output system
Adopting a new pressure-resistant structure to feed, which greatly increases the output of the machine and ensures the stability of the machine.The straight-through discharge structure solves the problem of material blocking and stacking.
Application Fields
High-end shape sort,this model can remove seed,stem,thron from pepper
Cooperation Case
Our mahchine can be found everywhere in Thailand,China,India,Philippines,Algeria and others more conuntries.
Our Service
Our Service Team
Before sales services
We will help you know ahout our color sorter,meets your special requirementaccording to actual condition.
After sales services
1.Provide free training,consulting and technical support for users;
2.Provide personalized programs to the demands of customers;
3.Upgrade software for free for a life time;
4.Provide free warranty service for one year(except the wearing spare parts);
5.Provide 7*24 hours consultation and urgent servicce for users.
Packaging&Shipping
Our products use professionalwooden cases with PE plastic bag..Package size will depend on each model size.
Plaese feel free to inquire if you are interested in our procducts!
