Product Details:
|
| Power: | 220V/50HZ | Type: | Corn Sorting Machine |
|---|---|---|---|
| Condition: | New | Production Capacity: | 15-30T/H |
| Color: | Blue | Sorting Accuracy(%): | ≥99.99 |
| Power(w): | 6.0KW | ||
| High Light: | IOT sesame color sorter,sesame color sorter Machine,IOT plastic color sorting machine |
||
Technical Parameters
| MODEL | 6SXZ-640A |
| Chutes/Channels | 10/ 640 |
| Throughput(T/H) | 15-30 |
| Accuracy(Percent) | ≥99.99% |
| Power(Kwh) | 6.0 |
| Power Voltage | 220V/50Hz |
| Air compressure(Mpa) | 0.6-0.8 |
| Air Consumption |
≤3.9 |
| Weight(Kg) | 1820 |
| Dimension(L*W*H) |
3895*1621*1816mm |
Product Features
► IOT color sorter system
Highly humanized interface of human-machine interaction, Smart cloud interconnect,Remote control, accurate big data statistics and analysis.Call the multiple preset color selection modes at any time.
► HD image capture system
Full-color high-speed CCD sensor recognizes 0.04mm²area,Nikon camera,super high resolution,ultra-sensitive ,wide vision, low distortion.
► Multi-core parallel image processing system
Multi-core parallel image processing system, flexible matching and synchronous operation of color sorting/shape sorting.
► Intelligent high-frequency solenoid valve
Ultra-low air consumption, ultra-low carryover ratio, intelligent detect the working status of ejectors,avoid the fault and prolong the life of ejectors.
► Shadowless colorful spectrum LED
Taiwan Yiguang,shadow-less LED colorful light source, multi-angle shadow-less light path technology.
► Input and Output system
Adopting a new pressure-resistant structure to feed, which greatly increases the output of the machine and ensures the stability of the machine.The straight-through discharge structure solves the problem of material blocking and stacking.
Application Fields
This series model can sort different kinds of cereals,grains,beans,such as corn,wheat,oat,buckwheat,sesame,mung,peanut and so on
JIETAI Color Sorter'Advantages
A.Running Stable
Quality assurance,
long service life.
Non-invasive sorting for all-round protection of easy to damage and break materials.
B.Minimalist User Interface
Let you far away from debugging difficult and operation complex trouble.
C.Super Brain Identification
Intelligent sorting,accurate identification of extremely small color difference and extremely small heterochromatic area materials.
D.Intelligent Valve
Intelligent control of blowing frequency,It can be achieved optimized carryover and ultra-low air consumption.
Intelligent detection of valve running status which makes the failure and operation life of the valve under control.
E.Powerful Function
Shape selection and color selection,intelligent color sorting plans for flexible matching.
F.After-sale Without Worry
provide free training,consulting and technical support for users;
Provide free warranty service for one year(except the wearing spare parts)
Materials Sorting Performance
Our Workshop&Warehouse
Our company offers variety of products which can meet your multifarious demands.We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
Cooperation Case
At present, our products have been distributed to more than 50 countries and regions around the world, providing high-quality products and services to global customers.
Our Service
Our Service Team
Before sales services
We will help you know ahout our color sorter,meets your special requirementaccording to actual condition.
After sales services
① Provide free training,consulting and technical support for users;
② Provide personalized programs to the demands of customers;
③ Upgrade software for free for a life time;
④ Provide free warranty service for one year(except the wearing spare parts);
⑤ Provide 7*24 hours consultation and urgent servicce for users.
Plaese feel free to inquire if you are interested in our procducts!
